Query

Queries select events from object storage by target app, time range, and search expression. The query endpoint launches stream sub-apps (via run/input/objectStorage/query) which process matching events and stream them to the Fluent Bit sidecar output configured in apps/cloud/streamer/stream/config.yaml.

Query Console

The Query Console runs locally inside your cluster — no log data or query metadata leaves your infrastructure. The console communicates directly with the streamer pods over the cluster network (SQS or REST), and query results stream to your SIEM via the Fluent Bit sidecar. See security architecture for details on the zero-egress design.

The console provides a web GUI and CLI for submitting queries, with built-in sample queries and progress tracking via CloudWatch Logs.

Web GUI

Start the web console to author and submit queries from a browser:

python3 console.py --serve

The GUI runs at http://localhost:8080 by default. Use --port to change the port:

python3 console.py --serve --port 9090

Features:

Search expression editor with example queries
Filters for in-memory JavaScript filtering after fetch
Time range selector with preset durations
Target field to scope queries to a specific app prefix
Submit via SQS or REST — toggle between SQS queue submission and direct REST endpoint (/streamer/query)
Dry run — preview the JSON payload without submitting
Advanced options — processing time, result size limits, log levels, storage buckets

CLI

Submit queries directly from the terminal:

# Search for errors in the last 30 minutes
python3 console.py \
  --search 'severity_level=="ERROR"' --since 30m \
  --bucket my-bucket --queue-url $LOG10X_QUERY_QUEUE_URL --follow

# Dry run — print the JSON payload without sending
python3 console.py \
  --search 'http_code=="500"' --since 1h \
  --bucket my-bucket --dry-run

Option	Description
`--search EXPR`	Search expression (`==`, `&&`, `\|\|`, `includes()`)
`--since TIME`	Relative time range (`30s`, `5m`, `1h`, `2d`)
`--from` / `--to`	Absolute time range in epoch milliseconds
`--bucket BUCKET`	S3 bucket containing log files
`--index-bucket BUCKET`	S3 bucket containing index objects (defaults to `--bucket`)
`--queue-url URL`	SQS queue URL (or set `LOG10X_QUERY_QUEUE_URL` env var)
`--target PREFIX`	App/service prefix (default: `app`)
`--processing-time DUR`	Max processing time (default: `60s`)
`--result-size SIZE`	Max result volume (default: `10MB`)
`--log-levels LEVELS`	Comma-separated log levels (default: `ERROR,INFO,PERF`)
`--filters EXPR`	JavaScript filter expressions for in-memory filtering
`--dry-run`	Print JSON payload without sending
`--follow`	Poll CloudWatch Logs until query completes
`--region REGION`	AWS region (default: `us-east-1`)

Requirements

Python 3.6+ (no external dependencies for the web GUI)
boto3 — required only for SQS submission and CloudWatch Logs polling. Install with pip3 install boto3
AWS credentials — configured via aws configure or AWS_ACCESS_KEY_ID/AWS_SECRET_ACCESS_KEY environment variables

The console is at $TENX_MODULES/apps/cloud/streamer/console in your local config, or on GitHub at streamer/console.

REST API

Submit queries directly via HTTP POST to the streamer endpoint:

curl -X POST http://localhost:8080/streamer/query \
  -H "Content-Type: application/json" \
  -d '{
    "from": "now(\"-5m\")",
    "to": "now()",
    "search": "severity_level == \"ERROR\""
  }'

The query endpoint returns HTTP 200 to acknowledge receipt. Matched events are processed by stream sub-apps (launched by the query module) and streamed to the Fluent Bit sidecar via the forward output configured in apps/cloud/streamer/stream/config.yaml. Check the Fluent Bit container logs for output:

kubectl logs -n log10x-streamer -l app=streamer-10x -c fluent-bit --tail=50

For the full query configuration reference, see Object Storage Query.

Sample Queries

Query for ERROR events in the last 5 minutes

Query events by severity_level enriched from log level fields:

curl -X POST http://localhost:8080/streamer/query \
  -H "Content-Type: application/json" \
  -d '{
    "from": "now(\"-5m\")",
    "to": "now()",
    "search": "severity_level == \"ERROR\""
  }'

Query for ERROR or FATAL events containing POST

Combine severity_level with text search using includes():

curl -X POST http://localhost:8080/streamer/query \
  -H "Content-Type: application/json" \
  -d '{
    "from": "now(\"-15m\")",
    "to": "now()",
    "search": "(severity_level == \"ERROR\" || severity_level == \"FATAL\") && includes(text, \"POST\")"
  }'

Query with a fixed time range

Use epoch milliseconds for precise time ranges (multiply seconds by 1000):

# 2026-01-22T09:00:00Z = 1769072400000
# 2026-01-22T11:00:00Z = 1769079600000
curl -X POST http://localhost:8080/streamer/query \
  -H "Content-Type: application/json" \
  -d '{
    "from": "1769072400000",
    "to": "1769079600000",
    "search": "severity_level == \"ERROR\""
  }'

Query with extended processing time

Use processingTime for large time ranges or high-volume data:

curl -X POST http://localhost:8080/streamer/query \
  -H "Content-Type: application/json" \
  -d '{
    "from": "now(\"-1h\")",
    "to": "now()",
    "search": "severity_level == \"ERROR\"",
    "processingTime": "parseDuration(\"5m\")"
  }'

Query with result size limit

Use resultSize to cap the volume of returned data:

curl -X POST http://localhost:8080/streamer/query \
  -H "Content-Type: application/json" \
  -d '{
    "from": "now(\"-1h\")",
    "to": "now()",
    "search": "severity_level == \"ERROR\"",
    "resultSize": "parseBytes(\"100MB\")"
  }'

Query by country

Query events by country enriched from IP addresses via GeoIP lookup:

curl -X POST http://localhost:8080/streamer/query \
  -H "Content-Type: application/json" \
  -d '{
    "from": "now(\"-1h\")",
    "to": "now()",
    "search": "country == \"US\" && severity_level == \"ERROR\""
  }'

Query by HTTP status

Query events by http_code enriched via lookup tables:

curl -X POST http://localhost:8080/streamer/query \
  -H "Content-Type: application/json" \
  -d '{
    "from": "now(\"-1h\")",
    "to": "now()",
    "search": "http_code == \"500\" || http_code == \"503\""
  }'

Query by k8s namespace

Query events by k8s_namespace enriched from Kubernetes context:

curl -X POST http://localhost:8080/streamer/query \
  -H "Content-Type: application/json" \
  -d '{
    "from": "now(\"-30m\")",
    "to": "now()",
    "search": "k8s_namespace == \"production\" && severity_level == \"ERROR\""
  }'

Query Parameters

Parameter	Type	Description
`from`	Epoch ms	Start of the time range (inclusive). Use `now("-5m")` for relative time or a literal epoch like `1769076000000`.
`to`	Epoch ms	End of the time range (exclusive). Use `now()` for current time.
`search`	String	Search expression using enriched field names (e.g., `severity_level`, `http_code`, `k8s_namespace`). Must use enriched fields, NOT raw JSON fields like `stream`, `log`, or `docker`. See Sample Queries for working examples. Supports `&&`, `\|\|`, `==`, and `includes()`.
`filters`	List	Optional JavaScript expressions for in-memory filtering after events are fetched from storage.
`processingTime`	Duration	Optional max processing time (e.g., `parseDuration("5m")`). Defaults to 1 minute.
`resultSize`	Bytes	Optional max result volume (e.g., `parseBytes("10MB")`).
